In Pursuit of Musicality
Convergent Audio Technology SL1 Legend Preamplifier *SOLD*
SOLD
*Good working condition
*No box
Product Description
"The SL1 Legend's line stage has the uncanny ability to delineate musical parts while at the same time conveying a powerful, resounding whole." "The music flowed with both naturalness and acute precision." "Bass had crunching heft when it was on the recording, while cymbals, triangles and brass overtones had what can best be described as residence in the soundfield -- the antithesis of wispiness that seems to be more decay than attack." The phono stage "was so pure and natural, so truly neutral, that it essentially mirrored the preamp's line stage, even with the extra tubes and transformer in the circuit." "I always felt great anticipation when returning to listen to the SL1 Legend, this becoming with time contentment, and then admiration."
https://www.soundstagenetwork.com/equipment/cat_sl1_legend.htm
Specifications
-Gain (@1kHz): Line 25.8 dB (“high”) / 15.2 dB (“low”), Phono 47dB MM / 58 dB MC (low) / 64dB MC (high)
-Gain Tracking: Line .05dB, Phono .05dB
-Frequency Response: Line 0.1Hz to 1.5 MHz+0, -3dB Phono RIAA +/- 0.05dB 20Hz to 20kHz (MC & MM)
-Harmonic Distortion (@ 1 volt): Line less than .0001% Phono less than .0005%
-Slew Rate: Line 15 volts/microsec, Phono 10 volts/microsec
-Maximum Output (@1kHz): Line & phono 50 volts rms
-Input Overload: Line 1000 volts rms Phono MM 250 mv rms at 1kHz, MC 70 mv rms
-Noise: Line High 98 dBA, Low 109 dBA below2 volt output MM 80dB below 1mv input. (0.10uv EIN) MC high 96 dbA below 1mv input (0.018 EIN)
-Separation: Line greater than 100 dB Phono greater than 100 dB
-Input Impedance: Line 50 kohms, 20pf Phono 47.5 kohms, 180 pf (user adjustable) MC 2,000 ohms
-Output Impedance: Line 100 ohms, Phono 50 ohms
-Maximum Load: Line under 4000 pf, over 5000 ohms Phono under 4000 pf, over 10,000 ohms
Return & Refund Policy
• All Pre-Owned items have been tested before listing.
• NO WARRANTY.
• We encourage buyers to test and verify the equipment condition at our showroom (1 Coleman Street, The Adelphi, Unit 03-35) — pre-owned condition as shown on our listed page.
